80-tons all fibers resistance furnace

Uses:

Mainly used for structural parts preheat, annealing after welding process

Structure description:

Equipment consists of furnace body, door and door elevator, hot air circulation system, the furnace and the Taiwan workshop sand seal mechanism, trolley and the trolley drive system, to track, electric Unit Ribbon heating system, maintenance platforms, electronic control system components.

Features:

1, the device furnace refractory fiber insulation materials are folded modules, the thermal conductivity, heat a small super-energy storage structure, using the fiber structure. Reduce energy consumption, reduce production costs, but also extended the life of the furnace.
2, resistance ribbons evenly arranged in the furnace and the furnace is equipped with hot air circulation fan, the temperature uniform mixing, furnace temperature uniformity of better cross-section;
3, furnace and carts with the seal between the plug seal knife seal structure of sand, and were pressed by the furnace on both sides of the cylinder, when the negative pressure within the furnace when the furnace to prevent cold air inhalation, when the furnace When the pressure is to prevent the temperature inside the furnace gas to leak out, but can also cut off from the furnace heat radiation. The furnace to minimize heat loss, to protect the car will not be burned metal components to prevent thermal deformation of the furnace orbit plays an important role.
4, car to the top knife inserted installation argument electrical devices and limit switches, lead electric car out immediately cut off the heating element separating device power, car power devices introduced into the furnace power connection in place, safety and reliability;
5, car pressure, high temperature, bearing the weight of large
